Features
High-leverage joint, long handles and optimized cutting edges for an easier cut than with compact cable shears. Cuts solid copper or aluminum cables up to 2 AWG, stranded cables up to 2/0 AWG and fine stranded cables up to 4/0 AWG. Dual cutting areas: step cutting edges position cables close to the joint and the front cutting edge is used for the gradual cutting (“nibbling”) of larger cables. Easy one- or two-handed operation with minimal handle opening for large cable diameters. Slim head for better accessibility. Not suitable for steel-reinforced cables, e.g. ACSR. Adjustable, high-leverage bolted joint provides precise and smooth cutting. Pinch guard prevents operators’ fingers being pinched. Laser-hardened cutting edges (approx. 56 HRC). High-grade special tool steel; forged; oil-hardened.
Specifications
General Information
Brand KNIPEX
Part Number 95 11 225 SBA
Product Type Cable Shears
Packaging Retail
Country of Origin Germany
UPC 843221029739
California Residents Proposition 65 Warning
Physical Characteristics
Length 9.08″
Width 1.76″
Height 0.64″
Weight 0.37 kg
0.81 lb
Color Black & Red
Finish Burnished
Material High-Grade Forged Tool Steel
Durability Approx. 56 HRC
Details
Size Compatible Cables: Stranded, Fine Stranded, Solid
Cutting Capacity – Cu and Al Conductor: 29/32″
Wire Size: Up to 2/0 AWG (Solid and Stranded Cables), Up to 4/0 AWG (Fine Stranded Cables)
Grip Type Plastic Coating (6 1/4″)
Pliers Type Cable Shears
Jaw Width 1 1/4″
Jaw Length 1 1/4″
Jaw Thickness 1/2″
Features High-leverage joint, long handles and optimized cutting edges for an easier cut than with compact cable shears
Cuts solid copper or aluminum cables up to 2 AWG, stranded cables up to 2/0 AWG and fine stranded cables up to 4/0 AWG
Dual cutting areas: step cutting edges position cables close to the joint and the front cutting edge is used for the gradual cutting (“nibbling”) of larger cables
Easy one- or two-handed operation with minimal handle opening for large cable diameters
Slim head for better accessibility
Not suitable for steel-reinforced cables, e.g. ACSR
Adjustable, high-leverage bolted joint provides precise and smooth cutting
Pinch guard prevents operators’ fingers being pinched
Laser-hardened cutting edges (approx. 56 HRC)
High-grade special tool steel; forged; oil-hardened
