Heyco 00752000080 Reversible Ratchet Torque Wrench, 10-60 NM, 355 mm

Features

The Heyco 00752000080 Reversible Ratchet Torque Wrench is a reliable and safe tool, designed for accurate torque screw tightening with a release accuracy tolerance of ± 3% of scale value. Its user-friendly reversible ratchet and safety locking handle reduce any risk of injury. With a range of 10-60 NM and 355 mm length, this torque wrench complies with DIN EN ISO 6789 and ISO 1174-1 standards.

Specifications

General Information

Brand  Heyco

Part Number  00752000080

Product Type  Torque Wrench

Packaging  Retail

Country of Origin  Germany

UPC  4024089415018

California Residents  Proposition 65 Warning

Physical Characteristics

Length  355 mm

Weight  0.76 kg

1.67 lb

Color  Silver

Finish  Chrome-Plated

Material  Chrome-Vanadium Steel

Details

Torque Range ft lbs  8 – 44

Torque Range Nm  10 – 60

Features  Release accuracy tolerance ± 3% of scale value (in direction of actuation).

Safe torque release: Palpable (close gap release, Audible (“click” sound)

Easy and safe adjustment of the desired torque value by turning the handle

User-friendly reversible ratchet

DIN EN ISO 6789, Square according to DIN 3120, ISO 1174-1.

Chrome surface of the tube: matt

Scale housing with double scale: Nm (lbf.ft)

Safety locking of the handle due to blue rotary assembly – no risk of injury!

Ergonomically

With serial number and certificate.

Indispensable for the torque controlled screw tightening.

Delivery in sturdy Hexa plastic box.
