CRL BMNW24X24PNClick To Copy Polished Nickel 24″ BM Series Back-to-Back Towel Bar Without Metal Washers

Features

• Use Monolithic Tempered Glass
• Heavy 3/4″ (19 mm) Diameter Tubular Construction (1.5 mil Thick))
• No Metal Washers Creates a Sleek, Continuous Profile
• Several Sizes in Our Most Popular Finishes

Hole Diameter Required  1/2″ (12 mm)

Hole Spacing  24″ (610 mm) Center-to-Center

Thread Size  1/4″-20

Projection From Surface  2-1/2″ (63.5 mm)

Finish  Polished Nickel

Mounting Type  Glass Mount – Back To Back

Material  Brass

Construction  Tubular

Glazing Thickness  1/4 To 1/2

Finish/Color  Polished Nickel

Series  BM

Style Washers  No

Mounting Center To Center (Inches)  24

Diameter  3/4

Mounting Style  Glass mount

Center To Center (Inches)  24

Diameter (Inches)  3/4

Mounting Center To Center  24 in. (610 mm)

The CRL BM Series of Back-to-Back Towel Bars Without Metal Washers are constructed of 1.5 mil thick heavy brass tubing. Plastic washers are included to protect against glass-to-metal contact. Consists of one bar for each side of the door in four standard sizes. Custom sizes are available.
SPECIFICATIONS:
Material: 3/4″ (19 mm) Diameter Brass Tubing (1.5 mil thick)
Glass Thickness Range: 1/4″ to 1/2″ (6 to 12 mm)
Hole Diameter Required: 1/2″ (12 mm)
Thread Size: 1/4″-20
Center-to-Center Hole Spacing:
12″ Towel Bar = 12″ (305 mm)
18″ Towel Bar = 18″ (457 mm)
24″ Towel Bar = 24″ (610 mm)
30″ Towel Bar = 30″ (762 mm)
AVAILABLE SIZES:
Cat. No. BMNW12X12 12″ Towel Bar
Cat. No. BMNW18X18 18″ Towel Bar
Cat. No. BMNW24X24 24″ Towel Bar
Cat. No. BMNW30X30 30″ Towel Bar

.
