Features
- Fail-Safe/Fail-Secure: Field convertible from one mode to the other. However, AC intermittent solenoid must not be used continuously in either.
- Electric Strike
- Case: Approximately 1” x 3-3/8” x 1-5/8” deep.
- Designed for Adams Rite Deadlatches or Cylindrical Locksets with 1/2″ to 5/8″ Latch Bolt Projection
- For Use in Hollow Metal or Wood Doors and Jambs
- Strike Lip: Basic 7100 strike has lip of proper length for 1-3/4” thick door that closes flush with jamb edge. Where door thickness or jamb shape differs from this standard relationship, lip extension kits are available, specified by last dash number. Not available on 7101.
- Strike Opening: 5/8” x 1-7/16” x 1/2” deep. Bolt retainer jaw is stainless steel. Strike accepts bolt of any Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical latches.
- 4-7/8″ Faceplate
- Warranted Free From Defects In Workmanship And Materials Under Normal Use And Service
- Faceplate: Measures 1-1/4” x 4-7/8”. 7100 has flat faceplate; 7101 is radiused to match nose on inactive leaf in a pair of narrow stile glass doors. Available in a wide range of architectural finishes.
- Voltage: Available in 12 or 24 volt AC and DC. DC continuous units are silent, AC intermittent units “buzz” on operation.
Finish Black Anodized
Function Electrically Unlocked (Fail Secure)
Series 7100 Series
Strike Electric Strike
Amp Draw 0.17 Amps
Faceplate Shape Flat Face, Square Corners
Faceplate Size 4-7/8 In. X 1-1/4 In.
Operating Voltage 24VDC
Package Qty 1
Switch Type None
Color Black Anodized Aluminum
Color Code 315/335
Electric Strike, Hollow Metal, Wood Jambs, 24VDC, Fail Secure, Black
For use in aluminum jambs and stiles.
7100, 7101 Electric Strikes with 4-7/8″ faceplates are designed for Adams Rite deadlatches or cylindrical locksets with 1/2″ to 5/8″ latchbolt projection.
